Additional information
| Light Source | |
|---|---|
| Shape | |
| Lumen Output | |
| Input Voltage |
SIGN-1-11L
Sign & Pole Mount • SIGN11 Series
SIGN-1-11L
Sign & Pole Mount • SIGN11 Series
FEATURES:
- 5 – 7W, 12V LED modular sign light.
- Utilizes adjustable accent fixture head with directional light.
- Accommodates different beam spread reflectors and optic accessories.
- Modular components – field changeable LED module & beam spread reflectors.
- ETL outdoor wet location listed. IP67 standard.
- Machined from solid billet 6061-T6 corrosion resistant aluminum.
Specifications
Materials
Machined from billet 6061-T6 corrosion resistant aluminum with 304 stainless steel hardware. Available in 304/316 stainless steel or 360 brass upon request.
Voltage
12V AC/DC. Requires remote step down transformer.
Lamp Base/Socket
Innovative cone-shaped lamp base and receptacle socket maximize the surface contact area to dissipate heat more effectively. See ‘‘Resources’’ for details.
Finish
Polyester powder coat on all aluminum materials with RoHS compliant procedures. Anodized finish is available. Stainless steel and brass models are provided with brushed surface.
Wattage
5 or 7W HK LED.
Optics
Accepts up to 3 accessories (hexcel louver, optical lenses, dichroic color filters, etc.). Secured in place with metal snap ring.
Hood and Glare Shield
3 available hood options to suit any application. 3 optional glare shields (short, long, angled) to complement each hood choice. (See page 3 of Spec Sheet for details).
Light Engine
CRI 83. Available in CRI95 upon request. The chromaticity range is within a 3-step McAdam Ellipse. Standard CCT options are 2700K, 3000K, 4000K.
Dimming
MLV or ELV.
Compatible Accessories
